Killark AF8-50GG 1/2 Inch Hub Polyolefin Coated ZA12 Expansion Fitting with 8 Inch Movement
- MPN: AF8-50GG
- UPC: 783936155852
- PPN: HBL-AF8-50GG
CAD
$1850.94
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Description
1/2" Hub, Polyolefin Coated ZA12 Expansion Fitting With 8" Linear Movement
Features
- Superior corrosive resistant ZA12 zinc alloy casted body and end coupling
- A 40 mil Polyolefin exterior coating
- Includes type "A" phenolic insulating bushing
- PTFE synthetic fiber reinforced gasket with steel washer to help maintain a strong seal
- Tinned braided copper ring
- Rain, water and concretetight
- AF8 Coated Series Expansion fittings are for use with IMC or rigid conduit installations. The AF8 Coated Series adds additional corrosion resistance in applications where abnormal environmental conditions exist. This series still prevents damage of the electrical installations typically used in buildings and bridges by compensating linear movement due to temperature fluctuation or structural movement. This series provides maximum 8” conduit movement (4” in either direction).
Documentation & Downloads
Specifications
Key Specifications
- Country of Origin
- United States
- Finish Type
- Polyolefin Coated
- ARRA Compliant
- Contact Manufacturer
- Description - Invoice
- 1/2" ZA EXPANSION FITTING 8" MVMT COATED
- Harmonization Code
- 7907002000
- MSDS Flag
- No
- Material
- Zinc Alloy, ZA12
- Base Unit of Measure
- EA
- Carton - SCC-14 Next Lower Level Sub Pack
- 00783936155852
Hub Size1/2"
TypeExpansion
Class CodeD30
Freight Class Code06168002
Image Actual Or RepresentativeR
Sub Class CodeD30D240
SeriesAF8 Series
BOX SIZE(in)
NAICS Code3359323108
