Burndy

Burndy YAGB6CLTC516FXOEM HYLUGTM Cu Battery Terminal, 6 AWG, 5/16 Inch Stud, 7/8 Inch Strip Length

  • MPN: YAGB6CLTC516FXOEM
  • UPC: 781810563076
  • PPN: BUR-50001016

CAD

$13.32

/ EA

Available to Order

Lead times may vary. For an accurate estimate please contact us.

Available To Ship Immediately:0

Looking to buy a large quantity?

To View Branch Inventory And Your Custom Pricing

Spec sheet

Description

Cu Battery Terminal Lug Type, #6 AWG, Blue, 7 Index, 5/16 IN Stud, 7/8 IN Strip Length

Documentation & Downloads

Specifications

Dimensions

Dimension - L Length Overall mm41 mm
Dimension - Pad Width inch0.60 in
Dimension - Stud Size inch5/16 in
Dimension - Length Overall inch1.61 in
Dimension - Strip Length inch7/8 in

Certifications and Compliance

Certification - CSA ApprovedNo
Certification - UL RecognizedNo
Standards - RoHS Compliance StatusCM
UL ListedNo
Certification - ETLNo
Certification - cULusNo
Standards - RoHS CompliantYes

Conductor Related

Conductor - Copper Flex G Size6 AWG
Conductor - Copper Flex I Size6 AWG
Conductor - Copper Str Size6 AWG
Conductor - Copper Flex H Size6 AWG
Conductor - Copper Flex K Size6 AWG
Conductor TypeCU C Str-Size

General

ApplicationPower Connector
Physical Attribute - Number of Holes1
Temperature Rating194
TypeOEM Terminals
UPC 12 Digit7818105630766
Connector TypeTerminal
Plating TypeTin - Electro Plated
Trade NameHYLUG™
UPC781810563076

Electrical Ratings

Rating - KVA35 kV
Voltage - Maximum35000
Rating - Minimum Voltage600
HYLUGTM Cu Battery Terminal, 6 AWG, 5/16 Inch Stud, 7/8 Inch Strip Length
