Leviton PT500 Poke-Through Floor Box, 2-Gang, 5 Inch Diameter, Steel, cULus Certified
- MPN: PT500
- UPC: 078477380956
- PPN: LEV-PT500
CAD
$379.87
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
5" Diameter Poke-Through Device With Protective Cover. 2-Body Design, Adjustable Anchors, And Standard NPS Threaded Openings
Features
- Ease of Installation: Two-piece construction allows the device to self-level up to 4 degrees
- Superior Performance: Adjustable hardened steel anchoring clips securely lock unit inside a cored hole, while allowing for easy removals for inspections, adjustments, repairs, etc.
- Maximum Compatibility: Accommodates standard duplex receptacles or Decora™ single or duplex receptacles, as well as Lev-Lok and QuickPort® inserts. Multiple low voltage divider slots accommodate different receptacle sizes * Protective cover included. *Poke-Through covers are sold separately from the PT500 system ; All covers come with low voltage divider (except pre-wired versions) Click Here to view these device specifications on ARCAT
Documentation & Downloads
Specifications
Key Specifications
| Country of Origin | United States |
|---|
| RoHS Compliant | True |
|---|
Material Specifications
| Feature | Intumescent Block|Insulation|EMT Pipe|Data & Conduit Connectors |
|---|---|
| Plate Material | Steel |
| Mounting Flange | Aluminium |
|---|
Mechanical Specifications
| Conduit Feeds | Power Feed 3/4” EMT Conduit, Data Feed 1 1/2” EMT Conduit Connector |
|---|---|
| Cubic Inch Capacity | 23.7cu. in. |
| Poke-Through Hole | 5” to 5 1/4” Hole |
| Conduit Selection | 1 1/2” EMT Conduit for Data |
|---|---|
| EMT Pipe Size | 12" |
Product Features
| Device Type | Poke-Through Floor Box System |
|---|
| Type | Poke-Through |
|---|
Warranty
| Warranty | 2-Year Limited |
|---|
Environmental Specifications
| Duration Of Fire Protection | Certified for Fire Resistance in 1, 1-1/2 & 2hr fire rated concrete floors |
|---|
| Operating Temperature | -40°C to 70°C |
|---|
Standards & Certifications
| Applicable Standards | UL514A, UL263, CSA C22.2 No. 18.1, NOM ANCE |
|---|---|
| UL File No. | E92327, R40253 |
| Certification/Listing | cULus |
|---|
