Killark UGRS-20231FD3QW 20A 125V Square Receptacle Quick-Wire, 1 Inch Hub, Class I, Division 2
Killark UGRS-20231FD3QW 20A 125V Square Receptacle Quick-Wire, 1 Inch Hub, Class I, Division 2
- MPN: UGRS-20231FD3QW
- UPC: 783936125558
- PPN: HBL-UGRS-20231FD3QW
Spec sheet
Loading compare button...
In Stock
Company Stock:
00
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To view product inventory
CAD$1432.02/ EA
Description
20A 125V Square Receptacle Quick-Wire with Flip Lid - 1" D-TYPE
Features
- Available with Exclusive Breech-Lock Lid
- Patented lid notch allows for screwdriver, etc. to hold open lid for easier, two-hand installation.
- Factory Sealed Construction
- Copper-free aluminum (less than 4/10 of 1%) alloy resists corrosion
- Electrostatically applied and baked powder epoxy/polyester finish
- Dead Front Construction with Integral Switch – requires Hazardous Rated NEMA-Bladed Plug for operation
- Rotateable Design allows for installation flexibility
- The ACCEPTOR® UGRS-QW Hazardous Location Blade Style Receptacle complements the UGR-QW receptacle line. Used with ACCEPTOR® plugs, UGRS Receptacles utilize VERSAMATE® 30A mounting boxes. The rotateable design enables cover hinge location to be in most convenient position for application (may also be utilized with sheet metal enclosures which contain no arcing devices). UGRS-QW Panel Mounted Receptacles are classified for use with other NEMA bladed-type explosion-proof and dust ignition devices. Factory sealed construction specifies that no additional external seals are required (except in Group B applications).
Specifications
Specifications
- Country of Origin
- United States
- Hazardous Rating(s)
- Class I, Division 2, Groups B, C, D;Class I, Zone 2, Groups IIB+H2, IIA;Class II, Divisions 1 & 2, Groups F, G;Class III, Divisions 1 & 2
- Amperage Rating
- 20 A
- Number Of Poles
- 2
- Type
- Straight Blade
- Class Code
- D35
- Freight Class Code
- 06168002
- Image Actual Or Representative
- A
- Sub Class Code
- D35D261
- Hub Pattern
- Angled Feed-Thru
- Material
- Aluminum, Copper Free (less than 4/10 of 1%)
- Series
- UGRS Series
- Carton - SCC-14 Next Lower Level Sub Pack
- 00783936125558
Width5.500 in
Hub Size1"
Nema Rating3, 4, 4X, 7(B, C, D), 9(F, G)
Number Of Wires3
ARRA CompliantContact Manufacturer
Description - Invoice20A 125V SQR RECPT QW FL 1" D-TYPE
Harmonization Code8536694020
MSDS FlagNo
Factory SealedFactory Sealed
Current Rating100 A
Receptacle TypeDelayed Action
Base Unit of MeasureEA
