3M MV18BCK Scotchlok Butt Connector, Vinyl Insulated, 22-18 AWG, 0.125 Inch OD, 500 per Case
- MPN: MV18BCK
- UPC: 054007013129
- PPN: MMM-MV18BCK
CAD
$0.60
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
This connector has a wire range of 22-18 AWG with a case quantity of 500. This butt connector uses chamfered barrel ends to provide fast easy wire insertion from both ends and a built in wire stop for correct positioning. It must be crimped at ends.
Specifications
Key Specifications
| Brand | Scotchlok |
|---|---|
| Maximum Insulation Outer Diameter | 0.125 Inch |
| Terminal Type | Butt |
| RoHS EU Comments | RoHS 2011/65/EU compliant without exemption |
| Thickness | 0.031 Inch |
| Agency Approvals | UL and CSA |
| Conductor Sizes | 22 - 18 AWG |
| Trademark | Scotchlok |
| UL File Number | E23438 |
| Length | 1.02 Inch |
|---|---|
| Terminal Style | Standard |
| Barrel Length | 0.28 Inch |
| CSA File Number | LR22190 |
| Packaging | 1000 per bulk box |
| RoHS 2011/65/EU Compliant | Yes |
| Insulation Material | Vinyl |
| Barrel Style | Seamless |
