3M 5451A-CI-1A 3M QS-II Molded Rubber Splices 5451A-CI-1A, CN and JCN Cable, 25/28 kV, 1 AWG Stranded, 1/0 AWG Solid, 0.905-1.055 in, 1 per case
- MPN: 5451A-CI-1A
- PPN: MMM-5451A/CI-1A
CAD
$885.90
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
3M QS-II Molded Rubber Splices 5451A-CI-1A, CN and JCN Cable, 25/28 kV, 1 AWG Stranded, 1/0 AWG Solid, 0.905-1.055 in, 1 per case
Specifications
Key Specifications
| 3M ID | 80610592653 |
|---|---|
| China RoHS - Below MCV | Undetermined |
| Conductor Sizes - Stranded - Cable Insulation Thickness | 1 AWG (280 mils), 1 AWG (295 mils) |
| Insulation O.D. Range | 0.905 - 1.055 Inch |
| Number of Conductors | 1 |
| Product Technology | Molded Rubber |
| Shielding Type | Concentric Neutral (CN), Jacketed Concentric Neutral (JCN) |
| Trademark | 3M |
| Case Quantity | 1 |
|---|---|
| Conductor Sizes - Solid - Cable Insulation Thickness | 1/0 AWG (280 mils), 1/0 AWG (295 mils) |
| Connector Included | CI-1A |
| Insulation Outside Diameter Range | 0.905 - 1.055 Inch |
| Product Series | 5451A Series |
| Product Type | Splice |
| Splice Type | Inline |
| Voltage | 25/28 kV |
