IPEX 106461 6 Inch x 20 Foot Trenchless Raceway, Schedule 40 PVC, Lightweight, Grey
- MPN: 106461
- UPC: 622454432918
- PPN: IPX-106461
CAD
$42.71
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Spec sheet
Description
SceptaCon is one of the first PVC systems designed for the rigors of trenchless applications. It links seamlessly to existing PVC conduit infrastructure and allows utilities to standardize on PVC throughout their entire electrical system. And because SceptaCon is made to the same high standards as our Scepter Rigid PVC Conduit, contractors and electrical utilities can be assured of the same level of quality – above ground and below. SceptaCon delivers the performance, reliability and long life you expect from IPEX.
Features
- No cementing, lubrication or fusion required, SceptaCon's slide-in locking system and pre-installed, pre-lubricated gaskets allow contractors to create a water-tight seal by hand in seconds
- Can be assembled one pipe length at a time, then pulled underground, eliminating the need for long strings of pipe on the job
- Made from durable schedule 40 PVC, resistant to creasing, scoring or flattening when pulled past obstructions in the borehole, yet flexible enough to bend with underground twists and turns
- Lightweight and easy to handle and work with in all types of weather
Documentation & Downloads
Specifications
Key Specifications
- Length
- 20.000 ft
- Height
- 6.625 in
- Diameter
- 6"
- Length Imperial
- 20'
- Material
- PVC
- Country of Origin
- Canada
Width6.625 in
Weight1.732 kg
Full Length20'
Connection TypeSPxH
ColorGREY
NAFTAYes
