Weidmuller 4169330000 RS 100 Transparent Hood, Width 108 mm, Height 2.933 Inch, IP20
- MPN: 4169330000
- PPN: WDM-4169330000
CAD
$53.14
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
Hood, RS 100 Transparent, Cover profile, Width: 108 mm
Documentation & Downloads
Specifications
System Characteristics
- Version
- Cover profile
- Contact to terminal rail
- No
- Encapsulation option
- No
Cross-connectionNo
Protection degreeIP20
Approvals
- ROHS
- Conform
Dimensions And Weights
- Length
- 2,000 mm
- Width
- 108 mm
- Height
- 74.5 mm
- Net weight
- 557.5 g
Length (inches)78.74 inch
Width (inches)4.252 inch
Height (inches)2.933 inch
Material Data
- Insulating material
- PVC
- Comparative Tracking Index (CTI)
- ≥ 600
- Storage temperature, min.
- -25 °C
- Max. relative humidity during storage
- 80 %
- Operating temperature, max.
- 100 °C
- Temperature range, installation, max.
- 100 °C
ColourTransparent
UL 94 flammability ratingV-2
Storage temperature, max.55 °C
Operating temperature, min.-50 °C
Temperature range, installation, min.-25 °C
Classifications
- ETIM 6.0
- EC002848
- eClass 9.0
- 27-14-11-92
- eClass 10.0
- 27-14-11-92
ETIM 7.0EC002848
eClass 9.127-14-11-92
UNSPSC30-21-18-27
Notes
- Descriptive text technical data
- 3 heights are available for the cover profile and the end plates:TS mounting without cover: TS 32 = 45 mm, TS35x7.5 = 40.5 mmTS mounting with low cover: TS 32 = 89 mm, TS 35x7.5 = 84.5 mmTS mounting with high cover: TS 32 = 121 mm, TS 35x7.5 = 116.5 mmDirect mounting, without/low/high cover: 24 / 69 / 99 mmDimensions of the PCBThickness: 1.6 (±0.2) mm, width: 100 (+0.5) mmDimension of the RS section = length of the printed circuit board – 4.5 mmDimension of ADP section = PCB length - 1 mmExample:PCB length 160 mm, RS = 155.5 mm, ADP = 159 mm
