APC AP9628 Step-Down Transformer 2U 208V Input 120V Output Hardwire, 95.20 lb, CSA/UL Listed
- MPN: AP9628
- UPC: 731304249153
- PPN: APC-AP9628
CAD
$1783.58
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Spec sheet
Description
Step-Down Transformer 2U 208V Input 120V Output Hardwire, 95.20 lb, CSA/UL Listed
Features
- Transformer for Step-down or Step-up or Isolation — Step down transformer placed upstream of the UPS to avoid inrush current and saturation eliminating need to oversize transformer
Documentation & Downloads
Specifications
Additional
- Input Voltage
- 208 V
- Load Capacity
- 5000 VA
- Output Connector Type
- Hard Wire 3-wire (H N + E)
- Input Frequency
- 60 Hz ± 3 Hz
- Rack Units
- 2U
- Width
- 17.52 in (445 mm)
- Height
- 3.50 in (89 mm)
- Compliance
- CSA, UL Listed
- RoHS
- Compliant
- Storage Temperature Range
- -13 to 149 °F (-25 to 65 °C)
- Storage Humidity
- 0 to 95%
- Storage Altitude
- 0 to 50,000 ft
- Customs Number
- 8504320000
- Warranty
- 24 months
- Product Orientation
- No preference
Output Voltage120 V
Input Connector TypeHard Wire 3-wire (2PH + G)
Input Current Limit26 A
Efficiency90%
Mountingfront rack-mounted
Depth24.02 in (610 mm)
Weight95.20 lb (43.18 kg)
StandardsUL 1778
Operating Temperature Range32 to 104 °F (0 to 40 °C)
Operating Humidity0 to 95%
Operating Altitude0 to 10,000 ft
ColorBlack
WEEEEU market compliant with waste collection
TakeBackNo
