RAB 081333 Area Light LED XBAR1-LED75 75W 120-277V Variable Temp 90° Symmetrical Distribution Matte Black Finish Dimmable with Photocell Polycarbonate Lens
- MPN: 081333
- UPC: 061184813336
- PPN: RAB-081333
CAD
$446.34
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Spec sheet
Description
The XBAR-LED Series is a slim, round post-top area light with a colour selectable switch allowing you to choose a colour temperature of 3000K, 4000K, or 5000K on the XBAR1 and a dedicated colour temperature of 4000K or 5000K for the XBAR2.
Features
- Unit has a switch inside the housing that is set at a default CCT of 4000K that can be adjusted if needed.
- Sleek, Modern post top area light
Documentation & Downloads
Specifications
Key Specifications
- Country of Origin
- China
- Height
- 7.1 Inches
- Lumens
- 9536
- Efficacy
- 122.1
- THD
- 0.15
- CRI
- 80
- LED life
- 100,000 hours
- Materials
- Die Cast Aluminum
- Voltage
- 120-277V
- Finish
- Matte Black
- Lighting Controls
- Photocell
Width20.3 Inches
Depth28.7 Inches
Watts78.1
Operating Temperature-40C to +50C
PF0.9
Surge Protection6kV
LensPolycarbonate
CCTVK
Beam Distribution90° Symmetrical Distribution
DimmableYes
