nVent Hoffman ATEX3003YZVM Large-Volume ATEX Purge System Type Y, Z and Ex [pz], 90CF, Vertical Mount

Large-Volume ATEX Purge System Type Y, Z and Ex [pz], 90CF, Vertical Mount
  • MPN: ATEX3003YZVM
  • UPC: 783510173630
  • PPN: HOF-ATEX3003YZVM
  • UNSPSC: 39121331

Spec sheet

Loading compare button...

In Stock

Company Stock:

00

Lead times may vary. For an accurate estimate please contact us.

Looking to buy a large quantity?

To view product inventory

Description

Large-Volume ATEX Purge System Type Y, Z and Ex [pz], 90CF, Vertical Mount

Features

  • Vertical mount (VM) or horizontal mount (HM)
  • Available in 90 cubic feet maximum enclosure volume model
  • System face plate and mounting plate: Type 316 stainless steel tumble finish
  • Regulator body: zinc with enamel finish
  • Manifold body: anodized aluminum with Type 316 stainless steel valves
  • Enclosure pressure gauge: aluminum with enamel finish
  • Gas supply gauge: poly case and nickel-plated tube
  • Enclosure protection vent (90 degree)
  • Enclosure supply and enclosure reference bulkhead fittings: Type 316 stainless steel
  • Fastener hardware available in aluminum and stainless steel
  • Rapid-exchange control valve
  • Explosion-proof differential pressure switch with “C” contacts for alarm

Specifications

Specifications

Length
18.10 inch
Height
10.80 inch
Width (millimetre)
203
Depth (D) (inch)
7.5
Height (H) (millimetre)
356
Volume (cubic metre (duplicate))
2.55
Weight (pound)
17.5
Color
Unpainted
Material
Stainless Steel 316L
Cubic Capacity
90 cubic ft
Width18.40 inch
Weight17.50 pound
Depth (D) (millimetre)189
Height (H) (inch)14
Volume (cubic foot)90
Weight (kilogram)8.2
Modification ServicesYes
FinishTumble
Size90CF in
