Killark B7EP Junction Box, 3.63 x 5.88 x 5.06 Inch, Class I, II, III, BCDEFG, Cast Aluminum, Type 4
- MPN: B7EP
- UPC: 783936020341
- PPN: HBL-B7EP
- UNSPSC: 39121314
CAD
$1334.71
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Spec sheet
Description
B7E Series, 3.63 X 5.88 X 5.06, Class I, II, III, BCDEFG, Cast Aluminum, Type 4, Bolted Enclosure
Features
- High strength, lighter weight, corrosion resistant copper free cast aluminum construction.
- Cover bolts of 316 grade stainless steel for maximum protection from corrosion.
- Cover o-ring, Nitrile (BUNA-N) material, supplied standard for a Type 4X rating.
- Mounting lugs are bolt on, made from ductile aluminum alloy.
- Conduit and device openings factory or field installed.
- Copper-free cast aluminum construction - high strength, lighter in weight, and corrosion resistant. Quick release, captivated cover bolts of 316 grade stainless steel - triple-lead bolts require only 3-1/2 turns to disengage. Stainless steel (316 grade) f
Specifications
Key Specifications
- Country of Origin
- Mexico
- Hazardous Rating(s)
- Class I, Divisions 1 & 2, Groups B, C, D;Class I, Zones 1 & 2, Groups IIB+H2, IIA;Class II, Divisions 1 & 2, Groups E, F, G;Class III, Divisions 1 & 2
- Color
- Gray
- Special Features
- Copper-free cast aluminum construction - high strength, lighter in weight, and corrosion resistant. Quick release, captivated cover bolts of 316 grade stainless steel - triple-lead bolts require only 3-1/2 turns to disengage. Stainless steel (316 grade) f
- Cover Type
- Bolted
- ARRA Compliant
- Contact Manufacturer
- Description - Invoice
- ENCL, PRISM 3.62 X 5.81
- Harmonization Code
- 8536908530
- Lead Time
- 15 wk
- Order Multiple
- 1 EA
- Sub Class Code
- D25D252
- Gross Weight with Packaging
- 11.2
- Series
- B7E Series
- BOX SIZE
- (in)
- Master Pack Description
- Each
Width9.250 in
ApplicationLocations made hazardous due to the presence of flammable gases or vapors, combustible dust, or easily ignitable fibers and flyings, and areas which are subject to corrosion, weather, and dampness. Petroleum refineries, chemical and petrochemical plants w
NEMA Rating3, 4, 4X
TypeJunction Box
Nema Rating3, 4, 4X
Class CodeD25
Freight Class Code06316011
Image Actual Or RepresentativeR
MSDS FlagNo
Returnable IndicatorYes
CSA File NumberLR11716
MaterialCopper-free aluminum
Base Unit of MeasureEA
Carton - SCC-14 Next Lower Level Sub Pack00783936020341
NAICS Code3359326103
Certifications
- EU RoHS Indicator
- Contact Manufacturer
