Square D AP504GLFI Elbow, I-Line Busway, 400A, 600VAC, 3 phase, 4 wire, front inside, Al, plug in, 18in x 18in
- MPN: AP504GLFI
- UPC: 785901436997
- PPN: SCH-AP504GLFI
- UNSPSC: 39131701
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Description
I-Line Busway offers a complete line of compatible, sandwich-type feeder and plug-in busway lengths and fittings. I-Line's plug-in busway has options from 225A to 5000A with aluminum or copper conductors; its feeder busway from 800A to 5000A. I-Line busway is constructed with three pole and four pole full neutral configurations for system voltages to 600 volts. This elbow has an aluminum bus rated at 400A at 600VAC. This busway component is configured for a 3 phase, 4 wire system and has a 50 percent capacity integral ground bus.
Features
- Part of a family of compatible lengths and fittings for flexible design choices
- Sandwich-type construction for improved voltage drop
- Rated up to 600V, up to 5000A for copper conductors and 4000A for aluminum
- Rated for 100% continuous current
- 3 pole and 4 pole full neutral configurations
Documentation & Downloads
Specifications
Key Specifications
| Country of Origin | United States |
|---|
| Weight | 15640 g |
|---|
Complementary Attributes
| Line Rated Current | 400-400 A |
|---|
| Ue Rated Operational Voltage | 600 V AC |
|---|
Important Information Attributes
| Carbon Footprint Of The Distribution Phase A4 | 30.08109826308222, 30 kg CO2 eq. |
|---|---|
| Carbon Footprint Of The Installation Phase A5 | 2.0390334826906433, 2 kg CO2 eq. |
| Carbon Footprint Of The Use Phase B2 B3 B4 B6 | 225 kg CO2 eq., 225.28756715066189 |
| Local Publishable Date | 2026-09-04 |
| Weee Scope | In |
| Scope Perimeter | Outside of Europe |
| Reach Full Compliance Status | Free of Substances of Very High Concern above the threshold |
| Reach Compliance Directive | Free of Substances of Very High Concern above the threshold |
| Rohs Eur Status | Compliant |
| Rohs Eur Full Compliance Status | Compliant |
| China Rohs Label | 1 |
| Without Single Use Plastic | No |
| Product Kit Identifier | N |
| Material | aluminium: busbar |
| Product Availability | Non-Stock - Not normally stocked in distribution facility |
| Protection Type | 50 percent capacity integral ground bus |
| Returnability | Yes |
| Sustainable Packaging | No |
| Wiring Configuration | 4-wire |
| Data Source | extrapolated product |
| Width Nominal | 18 in |
| Customs Code | 8544499000 |
| Functional Unit Description | Other switchgear and controlgear solutions mentioned in the scope (e.g. fuses TC32, all-or-nothing relays TC94, Measuring relays and protection equipment TC95), apply the general rules of PCR and mention in the accompanying report the functional unit, the reference product characteristics, the reference lifetime and the use scenario which are applied consistently with the relevant IEC technical standards. |
| Functional Unit Unit | Unit |
| Recyclability Potential In % | 87 |
| Carbon Footprint Of The End Of Life Phase C1 To C4 | 22 kg CO2 eq., 22.423874062716504 |
|---|---|
| Carbon Footprint Of The Manufacturing Phase A1 To A3 | 132 kg CO2 eq., 131.53078766876882 |
| Local Data Status | Publishable |
| Return Indicator | Y |
| Weee Product Category | 5 |
| Eoli Availability Display | No need of specific recycling operations |
| Reach Full Compliance Status Id | NOT_CONTAINING_SVHC |
| Rohs Eur In Scope | Yes |
| Rohs Eur Conformity Date | 1911 |
| China Rohs In Scope | No |
| With Recycled Cardboard | Yes |
| Product Contributes To Saved And Avoided Emissions | No |
| Installation Direction | horizontalfront inside |
| Phase | 3 phase |
| Product Or Component Type | elbow |
| Range Of Product | I-Line |
| Software Version | v6.2.4 |
| Total Lifecycle Carbon Footprint | 411 kg CO2 eq. |
| Database Version | 2024-07 |
| Length Total | 18 in |
| Nbr. Of Units In Pkg. | 1 |
| Warranty In Months | 18 |
| Functional Unit Quantity | 1 |
| Reference Lifetime In Y | 20 |
Environment Attributes Main
| China Rohs Regulation | Product out of China RoHS scope , Pro-active China RoHS declaration (out of China RoHS legal scope) |
|---|---|
| Reach Free Shvc | Yes |
| Toxic Heavy Metal Free | Yes |
| Carbon Footprint | 411.36236062792005 |
| Eu Rohs Directive | Compliant |
| Packaging Without Single Use Plastic | No |
| Reach Regulation | Free of Substances of Very High Concern above the threshold |
| Pep Verification Date | 2025-01-31 |
| Psr Version | PSR-0005-ed3.1-EN-2023 12 08 |
| Take Back | No |
|---|---|
| Recycled Metal Content At Cr Level | 0 % |
| Mercury Free | Yes |
| Environmental Disclosure | ENVPEP2412021EN |
| Packaging Made With Recycled Cardboard | Yes |
| Reach Free Of Svhc | Yes |
| Pep Code | ENVPEP2412021EN |
| Pcr Version | PCR-4-ed4-EN-2021 09 06 |
General Attributes
| Phase | 3 phase |
|---|---|
| Range Of Product | I-Line |
| Product Or Component Type | elbow |
|---|
Contractual Warranty Attributes
| Warranty | 18 months |
|---|
