PMA SLND-M120 Connectors-Straight
- MPN: SLND-M120
- UPC: 786209970909
- PPN: T-B-SLND-M120
CAD
$2.44
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Description
Smart Line Straight Grey One-Piece Connector with Integral Cone Seal, Material Polyamide 6, Thread Size - M12x1.5
Features
- Easy push-in installation
- Easy re-opening with screwdriver
- Space savings due to compact design
- Self-extinguishing, free of halogens and cadmium
- Excellent impact strength
- Fits both conduit profiles - fine (T) and coarse (G)
Documentation & Downloads
Specifications
European Specifications (ETIM)
- ETIM
- EC001176 Screw connection for corrugated plastic hose
- Degree of protection (IP)
- IP66
- Revolving thread
- N
- Type of connection
- Snap connection
- Thread connection size
- M12 x 1.5
- Thread length
- 11mm
- Material
- Polyamide
- Colour
- Grey
- Approved in combination with protective conduit UR
- N
- Approved in combination with protective conduit Lloyd's Register
- N
Nominal diameter12mm
ModelStraight
Construction typeInternal thread
Thread typeMetric
Thread materialPolyamide
Total length34mm
Material sealingNo sealing
Approved in combination with protective conduit CSAN
Approved in combination with protective conduit DIN EN 61386-23N
Operating temperature-45 - +105°C
North American Specifications (UNSPSC)
- UNSPSC
- 39121420 Liquid tight connectors
- Brand Name
- PMA
- Size
- NW10
- Material
- Polyamide 6
IGCC4585 Liquid tight connectors
TypeConnectors-Straight
ConnectionM12x1.5
ColorGray
Packaging
- Inner Quantity
- 100
- Outer Dimensions (inches)
- 15.748x11.811x8.661
Outer Quantity1300
Weight Uom0.01 lbs. Each
