nVent Hoffman CSP3630 Concept Swing-Out Panel, fits 36 Inch x 30 Inch, Light Gray, Steel
- MPN: CSP3630
- UPC: 783510125004
- PPN: HOF-CSP3630
- UNSPSC: 39121321
CAD
$496.46
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Description
Concept Swing-Out Panel, fits 36 Inch x 30 Inch, Light Gray, Steel
Features
- CSPB panels, maximum swing is 94 degrees
- CSP panels, maximum panel swing is 106 degrees
- Distance from panel surface to door when in the latched position is 1.71 in. (43 mm) for solid doors and 1.45 in. (37 mm) for window doors
- Kits include panel, brackets and hardware to mount to the front flange
Documentation & Downloads
Specifications
Key Specifications
| BABA | Contact Manufacturer |
|---|---|
| Width (W) | 707 |
| Finish | Powder Coated |
| Fits Enclosure Size | 914 x 762 |
| Works With | NEMA |
| Material | Steel |
| Color | LtGray |
| Height (H) | 858 |
|---|---|
| Product Family | Concept |
| Thickness (T) | 2.66 |
| Weight | 33 |
| Sub Brand | Concept |
| Size | fits 36.00x30.00 in |
