Nvent Hoffman

Nvent Hoffman CTMB4001L CT Mounting Base, 400 Amp, Steel, 1-Phase, Galvanized Finish, AIC 50,000

CT Mounting Base, 400 Amp, Steel, 1-Phase, Galvanized Finish, AIC 50,000
  • MPN: CTMB4001L
  • UPC: 783510156381
  • PPN: HOF-CTMB4001L
  • UNSPSC: 39121319

Spec sheet

Loading compare button...

In Stock

Company Stock:

00

Lead times may vary. For an accurate estimate please contact us.

Looking to buy a large quantity?

To view product inventory

CAD$583.69/ EA

Description

CT Mounting Base accommodates the difference between line and load connections inside a CT cabinet. This CT Mounting Base 1-Phase Mechanical Lugs, CTMB4001L item rated 400 Amp with a material of Steel color Unpainted.

Features

  • Spacing for bar-type current transformer that conforms to ANSI 12.11
  • Conductor provisions: either mechanical lugs or 1/2-in. bolt on 1-3/4-in. centers with nut, spring and flat washer
  • Neutral bar with 10-32 tap screw
  • 12-gauge galvanized formed base has electrically isolated mount/termination platform

Specifications

Specifications

BABA
Contact Manufacturer
Thickness (T)
2.05
AIC (Ampere Interrupting Capacity) Rating
50,000
Max Voltage AC
600
Service Type
1Ø3W
Weight
24
Material
Steel
FinishGalvanized
Connection TypeLugs
Current400
Wire Size(3) 750 MCM - 1/0
CT Provision Quantity2
Works WithIEC

Downloads
