nVent Hoffman CTMB8003 3-Phase Mounting Base Studs 400-800 Amp, Galvanized Steel
- MPN: CTMB8003
- UPC: 783510144371
- PPN: HOF-CTMB8003
- UNSPSC: 39121319
CAD
$611.69
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Description
CT Mounting Base accommodates the difference between line and load connections inside a CT cabinet. This CT Mounting Base 3-Phase Studs, CTMB8003 item rated 400-800 Amp with a material of Steel color Unpainted.
Features
- Spacing for bar-type current transformer that conforms to ANSI 12.11
- Conductor provisions: either mechanical lugs or 1/2-in. bolt on 1-3/4-in. centers with nut, spring and flat washer
- Neutral bar with 10-32 tap screw
- 12-gauge galvanized formed base has electrically isolated mount/termination platform
Documentation & Downloads
Specifications
Key Specifications
- BABA
- Contact Manufacturer
- Thickness (T)
- 2.05
- AIC (Ampere Interrupting Capacity) Rating
- 50,000
- Max Voltage AC
- 600
- CT Provision Quantity
- 3
- Works With
- NEMA
FinishGalvanized
Connection TypeStuds
Current400
Service Type3Ø4W
Weight34
MaterialSteel
