Nvent Hoffman

Nvent Hoffman CTMB8003L 3-Phase CT Mounting Base, 800 Amp, Steel, 3 CT Provision, 35 lb

3-Phase CT Mounting Base, 800 Amp, Steel, 3 CT Provision, 35 lb
  • MPN: CTMB8003L
  • UPC: 783510144418
  • PPN: HOF-CTMB8003L
  • UNSPSC: 39121319

Spec sheet

Loading compare button...

In Stock

Company Stock:

00

Lead times may vary. For an accurate estimate please contact us.

Looking to buy a large quantity?

To view product inventory

CAD$815.23/ EA

Description

CT Mounting Base accommodates the difference between line and load connections inside a CT cabinet. This CT Mounting Base 3-Phase, CTMB8003L item rated 800 Amp with a material of Steel color Unpainted.

Features

  • Spacing for bar-type current transformer that conforms to ANSI 12.11
  • Conductor provisions: either mechanical lugs or 1/2-in. bolt on 1-3/4-in. centers with nut, spring and flat washer
  • Neutral bar with 10-32 tap screw
  • 12-gauge galvanized formed base has electrically isolated mount/termination platform

Specifications

Specifications

BABA
Contact Manufacturer
Thickness (T)
2.05
AIC (Ampere Interrupting Capacity) Rating
50,000
Max Voltage AC
600
Service Type
3Ø4W
Weight
35
Material
Steel
FinishGalvanized
Connection TypeLugs
Current800
Wire Size(3) 750 MCM - 1/0
CT Provision Quantity3
Works WithNEMA
