Homac L 2-14 CU TP 4HOLE LUG WIRE 2 BOLT 1/4
- MPN: L 2-14
- UPC: 783786738861
- PPN: T-B-L 2-14
- UNSPSC: 39121409
CAD
$55.11
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Spec sheet
Description
Tin Plated Copper One-Hole Straight NEMA Lugs. wire size # 2 Stranded CU. Installing Dies 33, 162, 3/8, 10. Length 3-3/32 inch. Pad 5/8 inch wide x 1/1/2 inch long x 3/32 inch thick. (1) 17/64 inch hole. Barrel 1-1/4 inch. CSA. UL Listed.
Specifications
Additional Information
- Application
- General Applications
- Connection Type
- Compression
- Product Name
- ELECTRICAL TERMINAL<1000V
- Size
- 2-1/2 inch X 5/8 inch wide
- Standards
- UL E9809. CSA LR35518.
- Wire Size
- #2 AWG
Brand / LabelHomac
Effective Date20080619
Product TypeCompression Lug One Hole
Special FunctionsTin-Plated to resist corrosion. Produced from seamless electrolytic copper tubing which provides high conductivity and minimizes voltage drop. Marked with a catalog number, conductor sizes and die references.
Surface FinishingTin Plated
Ordering
- Country of Origin
- United States (US)
Selling Unit of Measureeach
Classifications
- WEEE Category
- Product Not in WEEE Scope
IDEA Granular Category Code (IGCC)4543 >> Wire connectors
