Homac L 300-48 CU TP 4HOLE LUG WIRE 300 BOLT 1/2
Homac L 300-48 CU TP 4HOLE LUG WIRE 300 BOLT 1/2
- MPN: L 300-48
- UPC: 783786739011
- PPN: T-B-L 300-48
- UNSPSC: 39121409
Spec sheet
In Stock
Company Stock:
00
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To view product inventory
CAD$108.40/ EA
Description
Copper Tin-Plated One-Hole Lugs, wire size 300 kcmil CU, Installing Dies 781, 17, 66. Overall Length 3-51/64 inches, Pad Width 1-1/4 inches, Pad Length 1-7/64 inch, Hole Diameter 9/16 inch. Pad Thickness 5/32 inch. Barrel Length 1-15/16 inch. CSA. UL listed.
Specifications
Additional Information
- Application
- General Applications
- Connection Type
- Compression
- Product Name
- ELECTRICAL TERMINAL<1000V
- Size
- 3-13/16 inch X 1-1/4 inch wide
- Standards
- UL E9809. CSA LR35518.
- Wire Size
- #2 AWG
Brand / LabelHomac
Effective Date20080619
Product TypeCompression Lug One Hole
Special FunctionsTin-Plated to resist corrosion. Produced from seamless electrolytic copper tubing which provides high conductivity and minimizes voltage drop. Marked with a catalog number, conductor sizes and die references.
Surface FinishingTin-Plated
Ordering
- Country of Origin
- United States (US)
Selling Unit of Measureeach
Classifications
- WEEE Category
- Product Not in WEEE Scope
IDEA Granular Category Code (IGCC)4543 >> Wire connectors
