Homac L 350-38 CU TP 4HOLE LUG WIRE 350 BOLT 3/8
- MPN: L 350-38
- UPC: 783786739080
- PPN: T-B-L 350-38
- UNSPSC: 39121409
CAD
$94.99
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Spec sheet
Description
Tin Plated Copper One-Hole Straight NEMA Lugs. wire size 350 kcmil CU. Installing Dies 71, 840, 18. Length 3-55/64 inch. Pad 1-5/16 inch wide x 1-7/64 inch long x 5/32 inch thick. (1) 13/32 inch hole. Barrel 2 inch. CSA. UL listed.
Specifications
Classifications
- WEEE Category
- Product Not in WEEE Scope
IDEA Granular Category Code (IGCC)4543 >> Wire connectors
Additional Information
- Application
- General Applications
- Connection Type
- Compression
- Product Name
- ELECTRICAL TERMINAL<1000V
- Size
- 3-7/8 inch X 1-5/16 inch wide
- Standards
- UL E9809. CSA LR35518.
- Wire Size
- 350 kcmil
Brand / LabelHomac
Effective Date20080619
Product TypeCompression Lug One Hole
Special FunctionsTin-Plated to resist corrosion. Produced from seamless electrolytic copper tubing which provides high conductivity and minimizes voltage drop. Marked with a catalog number, conductor sizes and die references.
Surface FinishingTin Plated
Ordering
- Country of Origin
- United States (US)
Selling Unit of Measureeach
