Homac L 6-14 CU TP 4HOLE LUG WIRE 6 BOLT 1/4
- MPN: L 6-14
- UPC: 783786739394
- PPN: T-B-L 6-14
- UNSPSC: 39121409
CAD
$39.79
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Spec sheet
Description
Tin Plated Copper One-Hole Straight NEMA Lugs. wire size # 6 Stranded CU. Installing Dies 24, 7. Length 2-1/8 inch. Pad 29/64 inch wide x 3/4 inch long x 5/64 inch thick. (1) 17/64 inch hole. Barrel 1-1/16 inch. CSA. UL listed. Bolt Size 1/4 inch.
Specifications
Classifications
- WEEE Category
- Product Not in WEEE Scope
IDEA Granular Category Code (IGCC)4543 >> Wire connectors
Ordering
- Country of Origin
- United States (US)
Selling Unit of Measureeach
Additional Information
- Application
- General Applications
- Connection Type
- Compression
- Product Name
- ELECTRICAL TERMINAL<1000V
- Size
- 2-1/8 inch X 1/2 inch wide
- Standards
- UL E9809. CSA LR35518.
- Wire Size
- #6 AWG
Brand / LabelHomac
Effective Date20080619
Product TypeCompression Lug One Hole
Special FunctionsTin-Plated to resist corrosion. Produced from seamless electrolytic copper tubing which provides high conductivity and minimizes voltage drop. Marked with a catalog number, conductor sizes and die references.
Surface FinishingTin Plated
