Square D PCSPCT190X10005 AccuSine+ auxiliary transformer - 1/5 - Step-up Transformer to 5 A

AccuSine+ auxiliary transformer - 1/5 - Step-up Transformer to 5 A

Square D PCSPCT190X10005 AccuSine+ auxiliary transformer - 1/5 - Step-up Transformer to 5 A

MPN: PCSPCT190X10005
PPN: SCH-PCSPCT190X10005
UNSPSC: 39121032

Spec sheet

Loading compare button...

Available to Order

Company Stock:

0

Lead times may vary. For an accurate estimate please contact us.

Looking to buy a large quantity?

To view product inventory

CAD$960.37/ EA

Loading add to cart quantity...

Description

AccuSine+ auxiliary transformer - 1/5 - Step-up Transformer to 5 A

Specifications

Complementary

Network Frequency: 50...400 Hz

Mounting Mode: by screws

Electrical Connection: studs2500 V

Height: body: 124 mm

Input Impedance: 0.5 Ohm

Continuous Thermal Current Rating Factor: 1.33 30 °C || 1 55 °C

Net Weight: 1.8 kg

[Ue] Rated Operational Voltage600 V AC 50...400 Hz

Current Transformer Ratio1/5

Widthbase width: 114.3 mm || body: 114.3 mm

Mounting Supportplate

Line Rated Current1 A

[Uimp] Rated Impulse Withstand Voltage10 kV (50 µs)

Depthbase depth : 119.1 mm || body : 55.6 mm

Specifications

Weight: 1.8 kg

Range Compatibility: AccuSine AccuSine PCS+ active harmonic filter || AccuSine AccuSine PFV+ electronic VAR controller

Product Or Component Type: auxiliary transformer

Secondary Current5 A

Accessory / Separate Part Categorymeasurement accessory

RangeAccuSine

Offer Sustainability

China Rohs Regulation: Product out of China RoHS scope. Substance declaration for your information.

Mercury Free: Yes

Eu Rohs Directive: Compliant

Weee: The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.

Rohs Exemption InformationYes

Toxic Heavy Metal FreeYes

California Proposition 65WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Environment

Product Certifications: cURus || CSA
