Square D PCSPCT190X1000 AccuSine+ auxiliary transformer - 5/1 - Step-down Transformer to 1 A

AccuSine+ auxiliary transformer - 5/1 - Step-down Transformer to 1 A

Square D PCSPCT190X1000 AccuSine+ auxiliary transformer - 5/1 - Step-down Transformer to 1 A

MPN: PCSPCT190X1000
PPN: SCH-PCSPCT190X1000
UNSPSC: 39121032

Spec sheet

Loading compare button...

Available to Order

Company Stock:

0

Lead times may vary. For an accurate estimate please contact us.

Looking to buy a large quantity?

To view product inventory

CAD$960.37/ EA

Loading add to cart quantity...

Description

AccuSine+ auxiliary transformer - 5/1 - Step-down Transformer to 1 A

Specifications

Specifications

Weight: 1.8 kg

Range Compatibility: AccuSine AccuSine PCS+ active harmonic filter || AccuSine AccuSine PFV+ electronic VAR controller

Product Or Component Type: auxiliary transformer

Secondary Current1 A

Accessory / Separate Part Categorymeasurement accessory

RangeAccuSine

Complementary

Network Frequency: 50...400 Hz

Mounting Mode: by screws

Electrical Connection: studs2500 V

Height: body: 124 mm

Input Impedance: 0.5 Ohm

Continuous Thermal Current Rating Factor: 1.33 30 °C || 1 55 °C

Net Weight: 1.8 kg

[Ue] Rated Operational Voltage600 V AC 50...400 Hz

Current Transformer Ratio5/1

Widthbase width: 114.3 mm || body: 114.3 mm

Mounting Supportplate

Line Rated Current5 A

[Uimp] Rated Impulse Withstand Voltage10 kV (50 µs)

Depthbase depth : 119.1 mm || body : 55.6 mm

Environment

Product Certifications: CSA || cURus

Offer Sustainability

China Rohs Regulation: Product out of China RoHS scope. Substance declaration for your information.

Mercury Free: Yes

Eu Rohs Directive: Compliant

Weee: The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.

Rohs Exemption InformationYes

Toxic Heavy Metal FreeYes

California Proposition 65WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
