Thomas & Betts 755DLR-N0380 DIRECT TEST ELBOW, 35KV, 600A DB
- MPN: 755DLR-N0380
- UPC: 783786516865
- PPN: T-B-755DLR-N0380
- UNSPSC: 39121421
CAD
$1486.37
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
600 Amp, 35KV, Direct Test Elbow, with Insulated Plug, Cap, Stud, Lug and Cable Adapter, Cable Insulation Diameter 1.515 inch to 1.780 inch. Aluminum Compression Lug. Conductor Size AWG or kcmil, Compressed Stranded 700/750 /Compacted Solid 900.
Specifications
Additional Information
- Brand / Label
- Elastimold
- Connection Type
- Compression
- Effective Date
- 20070913
- Includes
- Elbow Connector Housing, Compression Lug, Stud, Insulated Plug with Cap, Cable Adapter, Lubricant, Installation Instructions, Crimp Chart
- Material
- Aluminum Lug, EPDM Rubber Body
- Product Type
- Deadbreak Direct Test Elbow Connector
- Special Functions
- Fully Shielded, Fully Submersible. Comes with Insulated Plug, Cap, Stud, Lug and Cable Adapter
- Temperature Range
- -40 to +65 °C
ColorBlack
Current Rating600 A
Environmental ConditionsAll Weatheronditions °C
Insulation MaterialYes, EPDM Rubber
Product NameELECTRICAL CONNECTOR,>1000V
SizeT-Body 12.23 inch wide. 14.30 inch from bottom of T-Body to center of Bushing Interface entrance.
StandardsANSI/IEEE Standard 386
Voltage Rating35 kV
Classifications
- WEEE Category
- Product Not in WEEE Scope
IDEA Granular Category Code (IGCC)4586 >> Electrical connector assembly
Ordering
- Country of Origin
- United States (US)
Selling Unit of Measureeach
