Balluff BCC A314-A324-30-304-PX04A5-050 Double-Ended Cordsets BCC A314-A324-30-304-PX04A5-050
- MPN: BCC A314-A324-30-304-PX04A5-050
- PPN: BAL-BCC06J9
CAD
$159.03
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Description
With our robust double-ended cordsets, signals, data and power are transmitted continuously and securely. Choose the right connection for your application in your industry. Various cable types and plug connectors are available to you.
Documentation & Downloads
Specifications
Additional
- Operating Voltage
- 300 VDC / 300 VAC
- Cable Temperature Flexible Routing
- -20 to 80 C
- IP Rating
- IP67, IP68
- Connection 1
- 7/8"-Female, straight, 4-pin
- Approval/Conformity
- cULus, EAC, WEEE
- Conductor Cross-Section
- 1.5 mm2
- Material Contacts
- Brass
- Material Grip
- PUR
- Tightening Torque Pigtail
- 1.5 Nm
- Bending Radius Flexible Cable
- 10 x D
- Horizontal Travel Drag Chain
- 20 m
Number of Conductors4
Cable Temperature Fixed Routing-50 to 80 C
CablePUR black, 5.00 m, Drag chain compatible
Connection 27/8"-Male, angled, 4-pin
Cable Diameter8.00 mm 0.20 mm
Material Contact CarrierPUR
Material Cover NutDie-cast zinc
Cable Jacket ColorBlack
Bending Radius Fixed Cable7.5 x D
Acceleration Max Drag Chain5 m/s2
Traverse Speed Max Drag Chain300 m/min
