nVent Hoffman CED25 Double Protection Cable Gland M25, IP67, Light Gray, 30.5mm Diameter
- MPN: CED25
- UPC: 783510457518
- PPN: HOF-CED25
CAD
$211.08
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
The rubber cable gland is easy to mount, cables and pipes can be pulled through easily without tools. This Double Protection Cables Entry For Wall Mounted Enclosures, CED, CED25 item measures 30.5x30.5x21.3mm has a material of EPDM color Light Gray, finish Smooth.
Features
- Description: The rubber grommet is very simple to use. The installation does not require tools, which in turn means lower work cost. The “pushout” membrane is a permanent seal until it is penetrated by a cable or pipe. Suitable for holes in materials of 0.5 to 4 mm thickness.
- Material: EPDM, halogen free.
- Temperature resistance: -40 ºC to +110 ºC.
- Finish: RAL 7035.
- Protection: IP 67.
- The protection degree is maintained if the outside layer fails due to damage or external circumstances
- The double layer sock is the optimal solution if the outside layer is exposed to external circumstances such as high pressure water
- A potential disadvantage of the double layer however is that cables only pass through straight
- A single layer sock is available (CES) to allow cable passing through with an angle but the protection degree might be at risk if this single layer fails
Documentation & Downloads
Specifications
Key Specifications
- BABA
- Contact Manufacturer
- Width (W)
- 30.5
- Height 1 (H1)
- 15.3
- Cable Diameter Range
- 11
- Material
- EPDM
- Color
- Light Gray
- Package Quantity
- 50
- Protection Rating
- IP67
- Enclosure Material
- Mild Steel
Height (H)30.5
Depth (D)21.3
Diameter30.5
Hole Diameter25.5
FinishSmooth
Color CodeRAL 7035
Works WithIEC
Product FamilyWall Mounted
