Bussmann

Bussmann FWH-90B Eaton Bussmann series FWH high speed fuse, 700 Vac/dc, 90A, 200 kAIC at 1000 Vac, 50 kAIC at 500 Vdc, None, High speed fuse, Blade end X blade end, Stud

Eaton Bussmann series FWH high speed fuse, 700 Vac/dc, 90A, 200 kAIC at 1000 Vac, 50 kAIC at 500 Vdc, None, High speed fuse, Blade end X blade end, Stud
  • MPN: FWH-90B
  • UPC: 051712795814
  • PPN: BUS-FWH-90B

Spec sheet

Loading compare button...

Available to Order

Company Stock:

0

Lead times may vary. For an accurate estimate please contact us.

Looking to buy a large quantity?

To view product inventory

CAD$124.13/ EA

Description

Eaton Bussmann series FWH high speed fuse, 700 Vac/dc, 90A, 200 kAIC at 1000 Vac, 50 kAIC at 500 Vdc, None, High speed fuse, Blade end X blade end, Stud

Specifications

General

UPC
051712795814
Product Length/Depth
91 MM
Product Width
24 MM
Warranty
Not Applicable
Certifications
UL Recognized
EAN5027590021098
Product Height24 MM
Product Weight91 G
CompliancesCE Marked

Specifications

Fuse Indicator
None
Construction Size
Other
Connection
Blade end X blade end
Amperage Rating
90A
Watt Losses
15
Type
High speed fuse
Fuse Shape
centre-bolted tags
Amperage Rating Numeric
90 A
Voltage Rating
700 Vac/dc
Voltage Rating Numeric
500 V
Packaging Type
Standard
Interrupt Rating200 kAIC at 1000 Vac, 50 kAIC at 500 Vdc
Clearing (I2T)1600
Insulated Metal Gripping Lugs (IMGL)No
Utilization categoryOther
MountingStud
Rated switching capacity200 A
Breaking Capacity200 A
Pre Arc (I2T)360
Applicationprotection of DC common bus, DC drives, power converters/rectifiers and reduced voltage starters
Voltage TypeAC/DC
