Bussmann FWH-450A High Speed Fuse 450A RMS 750 Vac/Dc 5.3 Inch Width
- MPN: FWH-450A
- UPC: 051712150194
- PPN: BUS-FWH-450A
CAD
$240.55
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Description
High Speed Fuse 450A RMS 750 Vac/Dc 5.3 Inch Width
Documentation & Downloads
Specifications
Key Specifications
- Height
- 2.8 IN
- Width
- 5.3 IN
- Type
- FWH, North American style
- Voltage Rating
- 750 Vac, 750 Vdc
- Interrupt Rating
- 200 kAIC at 1000 Vac, 50 kAIC at 500 Vdc
- Mounting
- Stud
- Clearing (I2T)
- Clearing at 500V: 127000
- Pre Arc (I2T)
- 24700
Length2.17 IN
Weight.92 LB
ApplicationDC common bus, DC drives, power converters/rectifiers, reduced voltage starters
Amperage Rating450A RMS
ConnectionBlade end X blade end
Packaging TypeStandard
Fuse IndicatorNon Indicating
Watt Losses74W
