Bussmann

Bussmann FWP-800A High Speed Fuse 800A 700V AC/DC 200kAIC 14MM Width

High Speed Fuse 800A 700V AC/DC 200kAIC 14MM Width
High Speed Fuse 800A 700V AC/DC 200kAIC 14MM Width
High Speed Fuse 800A 700V AC/DC 200kAIC 14MM Width
High Speed Fuse 800A 700V AC/DC 200kAIC 14MM Width
  • MPN: FWP-800A
  • UPC: 051712796064
  • PPN: BUS-FWP-800A

Spec sheet

Loading compare button...

In Stock

Company Stock:

00

Lead times may vary. For an accurate estimate please contact us.

Looking to buy a large quantity?

To view product inventory

CAD$637.07/ EA

Description

High Speed Fuse 800A 700V AC/DC 200kAIC 14MM Width

Specifications

Specifications

Height
14 MM
Width
14 MM
Type
Fuse
Voltage Rating
250 Vac/dc
Amperage Rating
800A
Interrupt Rating
200 kAIC Vac, 50 kAIC at 700 Vdc
Construction Size
Other
Packaging Type
Standard
Fuse Shape
centre-bolted tags
Insulated Metal Gripping Lugs (IMGL)
No
Voltage Type
AC/DC
Rated switching capacity
200 A
Length169 MM
Weight567 G
Applicationprotection of DC common bus, DC drives, power converters/rectifiers and reduced voltage starters
Voltage Rating Numeric700 V
Amperage Rating Numeric800 A
ConnectionBlade end X blade end
MountingStud
Clearing (I2T)Clearing at 700V: 450000
Fuse IndicatorNone
Pre Arc (I2T)78000
Watt Losses140W

Downloads
