Bussmann TB100-12B Panel Mount Terminal Block Connector, 12-Pole, 30A, 300V, 3600V Breakdown Voltage
- MPN: TB100-12B
- UPC: 051712561624
- PPN: BUS-TB100-12B
CAD
$48.62
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
Panel Mount Terminal Block Connector, 12-Pole, 30A, 300V, 3600V Breakdown Voltage
Specifications
Key Specifications
| Mounting | Screw |
|---|---|
| Type | Double row, barrier |
| Connection | #6-32 TPI Screw |
| Operating Temperature | -40° to 130°C |
| Amperage Rating | 30A |
| Number Of Poles | Twelve-pole |
| Special Features | Breakdown voltage 3600V |
|---|---|
| Color | Black |
| Material | Tin-plated brass terminal, Nickel-plated brass philslot screw |
| Voltage Rating | 300V |
| Torque Rating | 9 lb-in |
General
| UPC | 051712561624 |
|---|---|
| Product Height | .41 IN |
| Product Weight | .43 LB |
| Compliances | RoHS Compliant |
| Product Length/Depth | 2.16 IN |
|---|---|
| Product Width | .88 IN |
| Warranty | Not Applicable |
| Certifications | Contact Manufacturer |
