Hubbell Premise Wiring

Hubbell Premise Wiring SFFLCSGNEI Fiber Optic Connectors, LC-Duplex, Snap-Fit, Flush, 1.700 Inch Width, Green

Fiber Optic Connectors, LC-Duplex, Snap-Fit, Flush, 1.700 Inch Width, Green
  • MPN: SFFLCSGNEI
  • UPC: 662620244716
  • PPN: HBL-SFFLCSGNEI
  • UNSPSC: 43223310

Spec sheet

Loading compare button...

In Stock

Company Stock:

00

Lead times may vary. For an accurate estimate please contact us.

Looking to buy a large quantity?

To view product inventory

CAD$38.08/ EA

Description

Fiber Optic Connectors, Snap-Fit, Flush, LC-Duplex, Zircon Sleeves, Green, Electric Ivory Housing.

Features

  • Snap Fit
  • Ivory Housing
  • Flush
  • LC Duplex
  • Green Adapter
  • Standard Product

Specifications

Specifications

Country of Origin
China
Width
1.700 in
Size
.58" X .76"
Color
Green
Insertion Loss
0.75 dB
Repeatability
0.1 dB
Service Life
500 matings
Standard
Telcordia GR-326-CORE;TIA-568-C.3;TIA-604 FOCIS-10
Temperature Rating
0C to 70C
Mounting Type
Flush
Class Code
A68
Freight Class Code
06168002
Image Actual Or Representative
A
Replaced Catalog Number
SFFLCGNEI;SFFLCGEI
Material - Mounting Hardware
Snap-In, Keystone
Base Unit of Measure
EA
Carton - Gross Weight per Pack
1.250 lb.
Carton - Pack Description
Carton
Carton - Total Units
25 EA
Lowest Level UOM
Each
Color - HousingIvory
Industry Standard(s)Telcordia GR-326-CORE;TIA-568-C.3;TIA-604 FOCIS-10
ApplicationData Outlet
Fiber Size125 Micron
MountingFlush
Return Loss55
Special FeaturesStandard Product
Sub BrandOptiChannel
ConnectivityReceptacle
StyleLC Duplex
Description - InvoiceFIBER, SNAP-FIT,FLSH,LC DUPLX,GN,ZIRC,EI
Harmonization Code8536700000
MSDS FlagNo
Sub Class CodeHPWALL2
MaterialCeramic
BOX SIZE4.362x2.000x6.550 (in)
Carton - Number of Sub Packs25
Carton - SCC-14 Next Lower Level Sub Pack662620244716
Each - Pack DescriptionEach

Certifications

EU RoHS Indicator
Yes
