Mersen A6D1-4/10R Fuse Amp-Trap 2000® 600V 1.4A Time-Delay Class RK1, PolyTube Body, 5 Inch Length
Mersen A6D1-4/10R Fuse Amp-Trap 2000® 600V 1.4A Time-Delay Class RK1, PolyTube Body, 5 Inch Length
- MPN: A6D1-4/10R
- UPC: 782001991616
- PPN: FER-A6D1-4/10R
Spec sheet
Loading compare button...
In Stock
Company Stock:
00
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To view product inventory
CAD$68.69/ EA
Description
Amp-Trap 2000® time-delay A6D-R fuses provide IEC Type 2 "no damage" protection to existing mains, feeders, and branch circuits serving motor and non-motor loads. A6D-R fuses will open fast enough under extreme fault conditions for maximum short circuit protection to prevent damage to motor starters, switches, and other circuit components, yet also provide the time-delay needed for motor in-rush currents. A6D-R fuses can be used to replace older 600V Class H, K or RK5 fuses already installed in the field.
Specifications
Specifications
- Rated voltage AC UL
- 600 V
- Frequency (Hz)
- 50/60 Hz
- AC or DC
- AC/DC
- Speed/Characteristic
- Time Delay
- AC Max I.R./Breaking Capacity: I1
- 200 kA
- Connection/Terminal Type
- Ferrule
- Length
- 5 in
Rated voltage DC UL600 V
Ampere Rating1.4 A
Fuse ClassClass RK1
MountingClip
Connection/Terminal MaterialTin-Plated Copper
Body/Insulating MaterialPolyTube
Weight0.146 lb
