Mersen FEY-11-31 Fuse Bases 600V 30A Class CC 2-pole, Crimp Connection
Mersen FEY-11-31 Fuse Bases 600V 30A Class CC 2-pole, Crimp Connection
- MPN: FEY-11-31
- UPC: 782001301361
- PPN: FER-FEY-11-31
Spec sheet
Loading compare button...
In Stock
Company Stock:
00
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To view product inventory
CAD$276.51/ EA
Description
Mersen’s complete line of single and dual pole in-line fuse holders accommodate either 1-1/2" x 13/32" (10 x 38 mm) midget or Class CC fuses. The fuse holders are designed for quick installation. Securing nuts or screws are captive thus speeding installation by reducing the need to locate and assemble loose components in the field. Three internal O-rings per pole seal the fuse holder providing a waterresistant compartment for the fuse. The captive O-rings are colored (blue for single pole and red for dual pole) for quick detection. Optional cone shaped insulator boots can be slipped on to provide a watertight seal (breakaway versions come with boots standard). Both single and dual pole versions have an optional breakaway feature which safely disconnects the load in case of a pole knockdown. Fuses remain safely encapsulated within the watertight fuse holder on the load side. Once the pole has been reinstalled the fuse holder can be easily reconnected.
Specifications
Specifications
- Rated voltage AC UL
- 600 V
- Frequency (Hz)
- 50/60 Hz
- ROHS Compliant
- Yes
- Fuse Class
- Class CC
- Fuse Type/Class
- Class CC
- Number of Poles
- 2-Pole
- Max Fuse Rating
- 30 A
- Body/Insulating Material
- Polyethylene
- Length
- 4.3 in
- Weight
- 0.2 lb
Rated voltage DC UL600 V
Ampere Rating30 A
AC or DCAC/DC
Short Circuit Current Rating (SCCR)200 kA
Design Details11-31
Fuse Installation MethodClip-in
Installation MountingIn-Line
Width2.96 in
Height0.99 in
