Weidmuller 1251680000 HDC HQM ALU CS
- MPN: 1251680000
- PPN: WDM-1251680000
CAD
$36.75
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
HDC enclosures, Size: HQ, Protection degree: IP65, Open base, Side-locking clamp on lower side, Standard
Documentation & Downloads
Specifications
General Data
| EMC housings | Yes |
|---|---|
| Material of locking element | Stainless steel, rust-proof |
| Series | HQ |
| Housing main material | Zinc diecast |
|---|---|
| Protection degree | IP65 |
| Surface finish | nickel-plated |
Approvals
| Approvals | CE |
|---|
Dimensions And Weights
| Width | 35 mm |
|---|---|
| Height | 41.6 mm |
| Mounting dimension - width | 32.2 mm |
| Net weight | 62 g |
| Width (inches) | 1.378 inch |
|---|---|
| Height (inches) | 1.638 inch |
| Mounting dimension - height | 13.4 mm |
General Descriptions
| Size | HQ |
|---|
| Protection degree | IP65 |
|---|
Dimensions
| Height of housing B | 20.5 mm |
|---|---|
| Total length housing | 46.3 mm |
| Hole pitch length A2 | 32.2 mm |
|---|---|
| Width housing C | 28.8 mm |
Version
| Clamp version | Side-locking clamp |
|---|---|
| Design of housing | Open base |
| Sealing | NBR |
| Suitable for ModuPlug | No |
| Type | Bulkhead (feed-through) |
| Design | Standard |
|---|---|
| Design of locking system | Side-locking clamp on lower side |
| Size | HQ |
| Top part/bottom part/lid | lower part |
Material
| Colour | Silver grey |
|---|
Classifications
| ETIM 6.0 | EC000437 |
|---|---|
| eClass 9.0 | 27-44-02-02 |
| eClass 10.0 | 27-44-02-02 |
| ETIM 7.0 | EC000437 |
|---|---|
| eClass 9.1 | 27-44-02-02 |
| UNSPSC | 30-21-18-01 |
Product Information
| Product information | The HQ version now offers particular protection - the bulkhead housing (cover and metal clamp) can be secured with a padlock. |
|---|
Environmental Product Compliance
| REACH SVHC | DIBP 84-69-5 |
|---|
Design
| Product family | HDC enclosures |
|---|---|
| Type | Bulkhead (feed-through) |
| Product type | Enclosures |
|---|
Temperatures
| Limit temperature | -40 °C ... 125 °C |
|---|
