Adaptaflex 260-1000 Index EMC Type A Cable Gland
- MPN: 260-1000
- UPC: 786210255729
- PPN: T-B-260-1000
CAD
$146.43
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
Cable Gland, Continuous Cable Sheath Allowing for a Ring of Outer Sheath Only to Be Stripped, M16 Thread, 10mm Thread Length, 26.7mm Gland Diameter, 24mm Across Flats Diameter, 4-6mm Cable Diameter Range, Nickel Plated Brass, Stainless Steel Spring, Rubber Seal, IP68
Specifications
North American Specifications (UNSPSC)
- UNSPSC
- 39121431 Cable gland connector
- Brand Name
- Adaptaflex
- Special Features
- Stripped Cable Sheath - Allowing the Outer Sheath to Be Completeley Stripped from the Cable
- Size
- M16
- Material
- Nickel Plated Brass, Stainless Steel Spring, Rubber Seal (TPE-V)
- Insulation
- IP68
IGCC4601 Cable gland connector
TypeIndex EMC Type A Cable Gland
ApplicationProvide Strain Relief and Connection for Conduit Systems
Conductor Range4.0 to 6.0mm
ColorBrass
Temperature Rating-40 Degrees C to +135 Degrees C
European Specifications (ETIM)
- ETIM
- EC000441 Cable screw gland
- Nominal thread size metric/PG
- 16
- Wrench width
- 24mm
- Suitable for cable diameter
- 4-6mm
- Material quality
- Brass
- Halogen free
- Y
- Degree of protection (IP)
- IP68
- Colour
- Other
- With locknut
- N
- Flat cable coupling
- N
- Operating temperature
- -40-+135°C
- For Ex-zone gas
- None
- EMC-version
- Y
Thread typeMetric
Thread length10mm
Hexagon angular dimension26.7mm
MaterialMetal
Surface protectionNickel-plated
Glass-fibre reinforcedN
Shock resistantN
Bend radius protection/trumpet flareN
ModelStraight
Strain reliefN
Explosion-tested versionN
For Ex-Zone dustNone
Packaging
- Outer Quantity
- 25
- Weight Uom
- 0.21 lbs. Each
Outer Dimensions (inches)1x1x1
