Industrial Fuse 4A 660V Length 50 Inch Width 56.299 Inch Height 22.441 Inch
Industrial Fuse 4A 660V Length 50 Inch Width 56.299 Inch Height 22.441 Inch
Bussmann

Bussmann TAC4 Industrial Fuse 4A 660V Length 50 Inch Width 56.299 Inch Height 22.441 Inch

  • MPN: TAC4
  • UPC: 051712392785
  • PPN: BUS-TAC4

CAD

$132.30

/ EA

Available to Order

Lead times may vary. For an accurate estimate please contact us.

Company Stock:

0

Looking to buy a large quantity?

To View Branch Inventory And Your Custom Pricing

Spec sheet

Description

Bussmann's industrial fuse is specifically engineered to provide reliable protection in high-stakes environments with a voltage rating of 660V and an amperage capacity of 4A. Its substantial dimensions, with a length of 139 mm and a width of 23 mm, make it an essential component for various industrial applications where robust electrical safety measures are required. Although it features a non-indicating design, the fuse's durability and performance ensure dependable operation, effectively safeguarding equipment from overload or fault conditions. For detailed specifications or to discuss particular requirements, contacting the factory is recommended.

Features

  • Engineered specifically for heavy-duty industrial and mass transit applications, this high-speed fuse safely operates at a maximum of 1200V AC and 660V DC. Its precise 4A current rating provides localized overcurrent protection, meaning it acts instantly during short circuits to isolate faults and prevent catastrophic damage to expensive auxiliary power lines, rail infrastructure controls, and instrumentation circuits.
  • Built to standard BS2692-1 specifications with a physical body size of 22mm x 139mm, this cartridge fuse features offset bolted tags (knife blade termination) designed for solid, vibration-resistant mounting.
  • This component is fully compliant with BS 2692-1 standards.

Documentation & Downloads

Specifications

Additional

Voltage
660V
Length
139 mm
Height
23 mm
Fuse Indicator
Non Indicating
Amperage4A
Width23 mm
Weight105 g
TypeIndustrial fuse
