Weidmuller 9200680000 LID 2,5M5 R
- MPN: 9200680000
- PPN: WDM-9200680000
CAD
$0.10
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
cable lug, terminal end,Insulated cable connector,1.5 mm² - 2.5 mm²,blue
Documentation & Downloads
Specifications
Classifications
- ETIM 6.0
- EC001059
- eClass 9.0
- 27-40-02-12
- eClass 10.0
- 27-40-02-12
ETIM 7.0EC001059
eClass 9.127-40-02-12
UNSPSC30-21-18-01
Connectors
- Conductor cross-section, max.
- 2.5 mm²
- Dimension
- ø 5 mm
- Identification colour
- blue
- Material/plastic
- PVC
- Plastic collar diameter (D)
- 5 mm
Conductor cross-section, min.1.5 mm²
Dimension (round plug)ø 5 mm
InsulationAvailable
Outside diameter (d)5 mm
Plastic collar length (b)10 mm
Dimensions And Weights
- Width
- 20.8 mm
- Depth
- 6.3 mm
- Net weight
- 0.9 g
Width (inches)0.819 inch
Depth (inches)0.248 inch
Approvals
- ROHS
- Conform
