Schneider Electric VW33MF020LD03 Locating Dowels for Lexium PAS, 3/8 x 12 mm, 20 Pieces

Locating Dowels for Lexium PAS, 3/8 x 12 mm, 20 Pieces
  • MPN: VW33MF020LD03
  • PPN: SCH-VW33MF020LD03

Spec sheet

In Stock

Company Stock:

00

Lead times may vary. For an accurate estimate please contact us.

Looking to buy a large quantity?

To view product inventory

CAD$134.92/ EA

Description

Engineered for precision and reliability in automation and control applications, these locating dowels from Schneider Electric are an essential component for the Lexium PAS system. Measuring 3/8 x 12 mm, this pack includes 20 pieces designed to ensure accurate alignment and assembly, facilitating smooth operation in motion control setups. Their robust construction provides durability while supporting the seamless integration of automation systems, making them a valuable addition for any project requiring dependable performance.

Specifications

Product Or Component Type
adaptor
Range Compatibility
Lexium CAS || Lexium PAS
Diameter
3.8 mm
Dimensions D1
9 mm
Toxic Heavy Metal Free
Yes
Pvc Free
Yes
REACH Compliance
Free of Substances of Very High Concern above the threshold
Country of Origin
Germany
Product CompatibilityPAS 44 linear axis 110 x 110 mm || CAS 44 linear axis 110 x 110 mm || CAS 34 cantilever axis 160 x 50 mm
Range Of ProductLexium linear motion
Length12 mm
Dimensions D212 mm (h6)
Mercury FreeYes
RoHS CompliancePro-active compliance
Warranty18 months
