Pass & Seymour LSSC5PW LS Series Fan Speed Control, 3-Speed, White, 1.28 Inch Depth, 4.185 Inch Height

MPN: LSSC5PW
UPC: 785007158113
PPN: P-S-LSSC5PW
UNSPSC: 39122206

$60.56

Available to Order from Manufacturer

Lead times may vary. For an accurate estimate please contact us.

Available To Ship Immediately:0

Loading add to cart quantity...

Looking to buy a large quantity?

To View Branch Inventory And Your Custom Pricing

Spec sheet

Compare

Description

LS Series Fan Speed Control, 3-Speed, White, 1.28 Inch Depth, 4.185 Inch Height

Features

Tough impact-resistant thermoplastic housing.
Power-failure memory.
Superior heat management: no time wasting break off tabs.
Exclusive screw-pressure-plate back wire terminals eliminates wire nuts.
Can be used with patented Snap-In Light Module (sold seperately).

Documentation & Downloads

Specifications

Key Specifications

Country of Origin	China
Height	4.185 in
Color	White
Material	Steel,Thermoplastic
Number of Poles	Single Pole
Standard	UL Listed
Operating Cycles	100000.0
Mounting Type	Wall Box
Indoor/Outdoor	Indoor
Load Rating	120V 5A (Fan Control)
Preset	Yes
Voltage	120 VAC
Number of Switches	1.0
Dimming Compatibility	Fan Speed Only
Switch Type	Slider; Rocker

Depth	1.28 in
Width	1.74 in
Finish	Matte
Product Line	Pass & Seymour
Type	Fan Speed Control
Special Features	Tough impact resistant thermoplastic, power failure memory, superior heat management
Wire Size	#14 - #12 AWG
Features	Variable Speed Fan Control
Requires Neutral Wire	No
Wire Connection Type	Screw Terminals
Application Sector	Multi-Dwelling Unit; Residential
Frequency Rating	60 Hz
Warranty Type	Limited Lifetime Warranty
Load Type	AC Fan Motor
