Mersen A70Q300-4 High Speed Fuse Amp-Trap® A70Q 700VAC 650VDC 300A Bolted Blade
Mersen A70Q300-4 High Speed Fuse Amp-Trap® A70Q 700VAC 650VDC 300A Bolted Blade
- MPN: A70Q300-4
- UPC: 782001141004
- PPN: FER-A70Q300-4
Spec sheet
Loading compare button...
Available to Order
Company Stock:
0
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To view product inventory
CAD$469.13/ EA
Description
A70Q Amp-Trap® high speed fuses were developed for inverter applications requiring extremely low I2t. A70Q fuses provide the most responsive protection for applications not required to sustain heavy overloads. Typically used for replacement purposes.
Specifications
Specifications
- Rated voltage AC UL
- 700 V
- Frequency (Hz)
- 50/60 Hz
- ROHS Compliant
- Yes
- Speed/Characteristic
- High Speed
- AC Max I.R./Breaking Capacity: I1
- 65 kA
- Connection/Terminal Type
- Blade
- Length
- 5.09 in
Rated voltage DC UL650 V
Ampere Rating300 A
AC or DCAC/DC
MountingBolted
Connection/Terminal MaterialTin-Plated Copper
Body/Insulating MaterialGMG
Weight0.95 lb
