Mersen Q097557 Protistor 17x27 aR High-Speed Fuse, 125 A, 250 VAC, Ceramic Body
- MPN: Q097557
- PPN: FER-Q097557
CAD
$312.29
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
Extremely high breaking capacity fuses: Protection of power semiconductors as per IEC standard 60269-1 and -4 250 V voltage rating as per IEC 33 gR class as per VDE 636-23 and IEC 60269.4
Specifications
Key Specifications
| Rated voltage AC UL | 250 V |
|---|---|
| Rated voltage AC IEC | 250 V |
| ROHS Compliant | Yes |
| Speed/Characteristic | aR |
| Mounting | Bolted |
| Melting I2t | 850 A²s |
| Indication System | Yes |
| Connection/Terminal Material | Copper |
| Body/Insulating Material | Ceramic |
| Width | 1.06 in |
| Height | 0.94 in |
| Rated voltage DC UL | 250 V |
|---|---|
| Ampere Rating | 125 A |
| AC or DC | AC |
| Fuse Size | 17x27 |
| Clearing I2t At Rated Voltage | 6920 A²s |
| AC Max I.R./Breaking Capacity: I1 | 250 kA |
| Indication System Type | Striker |
| Connection/Terminal Type | L Brackets |
| Power Dissipation at Rated Current Value | 12.3 W |
| Length | 2.14 in |
| Weight | 0.095 lb |
