Burndy PAT46T3SU0000 T3 Tech 15-Ton Battery Actuated Crimper, 18 VDC, C-Head, 2 Inch Jaw
- MPN: PAT46T3SU0000
- UPC: 621945625587
- PPN: BUR-50113152
- UNSPSC: 27112750
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
PATRIOT® Series, T3 Technology 15-Ton Battery Crimper, C-Head, Uncovered, No Case, No Batteries, No Charger, Makita Power
Features
- TRACK crimp locations with onboard GPS - BURNDY Exclusive!
- TRACE individual crimps with comments and output force validation
- TRANSMIT via Bluetooth® technology and sync data to the cloud
- C-head with 2” jaw opening with 355° head rotation
- Uses P Dies and U Dies with PUADP1 Adapter
- Bright LED worklight and Red/Green LED to validate output force
- Improved ergonomic design with more balance and better grip to reduce user fatigue
- Accepts 2.0Ah-6.0Ah Makita Lithium-ion Batteries
Specifications
Key Specifications
| Country of Origin | United States |
|---|---|
| ChannelSightWidgetId | 705 |
| Crimp Force Capacity | 15 ton |
| Die Type | P Die and U Die with PUADP1 Adapter |
| Height | 14.13 in |
| Operating Voltage | 18 VDC |
| Product Type | 15-Ton |
| Battery | No Batteries Included (Accepts 2.0Ah-6.0Ah Makita LI Batteries) |
| Sub Brand | PATRIOT® |
| Warranty | 5 year limited warranty, Lifetime warranty on INFINITY DRIVE®, 3 year warranty on batteries and charger |
| Width | 3.26 in |
| Class Code | B82 |
| Harmonization Code | 8467290090 |
| Sub Class Code | B82B82B |
| Series | PATRIOT® Series |
| Base Unit of Measure | EA |
| Carton - Gross Weight per Pack | 0.000 lb. |
| Carton - Pack Description | Carton |
| Carton - Total Units | 1 |
| Pallet Height | 41.375 in |
| Pallet Weight | 45.000 lb. |
| NAICS Code | 3339911151 |
| Application - For Use On | Copper, Aluminum, ACSR Terminals and Splices |
|---|---|
| Container Type | No Case/Bag |
| Description - Slang | T3 Tech, BURNDY T3, PATRIOT T3, T3, PAT46, 15-Ton |
| Dimensions | 18.44 in x 3.26 in x 14.13 in |
| Length | 18.44 in |
| Power Source | No Charger |
| Application | Crimping |
| Size | 18.44 in x 3.26 in x 14.13 in |
| Type | Crimper |
| Weight | 18.15 lb. |
| Battery Type | No Batteries Included (Accepts 2.0Ah-6.0Ah Makita LI Batteries) |
| Freight Class Code | 16027000 |
| Image Actual Or Representative | A |
| Crimping Ranges | Copper: #14 AWG Str. - 1500 kcmil; Aluminum: #8 AWG - 1250 kcmil; Ground Rod: 1/2"-1" diameter |
| Tool Type | Battery Actuated Crimper, T3 Technology |
| BOX SIZE | 11.875x19.563x16.063 (in) |
| Carton - Number of Sub Packs | 1 |
| Carton - SCC-14 Next Lower Level Sub Pack | 00621945625587 |
| Pallet - GTIN - Package | 70621945625586 |
| Pallet Length | 48.000 in |
| Pallet Width | 40.000 in |
