Pass & Seymour

Pass & Seymour 46001P Cast Aluminum Toggle Switch Cover, Gray, UL Listed, Mounts on 4 Inch Box

Cast Aluminum Toggle Switch Cover, Gray, UL Listed, Mounts on 4 Inch Box
  • MPN: 46001P
  • UPC: 785007179224
  • PPN: P-S-46001P

Spec sheet

Loading compare button...

In Stock

Company Stock:

00

Lead times may vary. For an accurate estimate please contact us.

Looking to buy a large quantity?

To view product inventory

CAD$45.03/ EA

Description

Cast Aluminum Toggle Switch Cover, Gray, UL Listed, Mounts on 4 Inch Box

Features

  • Adapter, frame, and cover are heavy cast aluminum.
  • No. 8-32 screws hold assembly firmly in place.
  • Covers comply with 2005 NEC Section 406.8(A) and 406.8(B)(2).
  • Mortar keys provide positive holding means within wall.
  • Neoprene gasket seals cover to frame. Moisture and dust cannot enter enclosure.
  • Two keys provided for lock.
  • Purchase enclosure and mounting plate separately.
  • Mounts on 4 in. or 4-11/16 in. box.

Specifications

Specifications

Depth
0.78 in
Color
Gray
Finish
Satin
Material
Aluminum,Cast Metals
Product Line
Pass & Seymour
Indoor/Outdoor
Indoor
Standard
UL/CSA Listed
Mounting Type
Box Mounted
Features
Moisture Resistant
Application Sector
Commercial
Cover Type
Mortared-In Applications
Height3.094 in
Length3.094 in
Width3.063 in
Country of OriginUnited States
Number of Gangs1
Number of Outlets1.0
FeaturesDust Resistant
Box Cover PositionVertical
TypeWeatherproof Cast Cover
Application SectorIndustrial
Special FeaturesMounting plate for toggle switch, mortared in application
