Schneider Electric BMXXCAUSBH018 Modicon M340 USB Connecting Cable, 1.8m Length

MPN: BMXXCAUSBH018
PPN: SCH-BMXXCAUSBH018

If you can't find the product or are unsure which one you need, please use the Product Selector tool below

$358.83

Available to Order

Lead times may vary. For an accurate estimate please contact us.

Available To Ship Immediately:0

Loading dialog...

Loading add to cart quantity...

Looking to buy a large quantity?

To View Branch Inventory And Your Custom Pricing

Spec sheet

Compare

Description

This programming cordset enables the connection between a Magelis XBT controller and a PC. It is equipped with one USB type mini-B male connector, PC side and one USB type A connector, controller side. It is 1.8 meters long.

Features

This authentic Schneider Electric cordset is designed for universal integration across your control architecture, providing a perfect mechanical fit for Modicon M340, Modicon M262, and Magelis/Harmony XBTGT or GTO graphic terminals. By establishing a direct link between your PC and target processors or Lexium servo drives, it eliminates communication failures and the compatibility guesswork often associated with third-party, non-industrial alternatives.
The cable features a standard USB Type-A male connector on the PC/terminal side and a rugged USB Mini-B male connector on the controller side. This standardized, plug-and-play configuration ensures a secure electrical connection to the PAC or servo drive, allowing control engineers to initiate firmware updates and diagnostics without needing specialized adapters.
Measuring exactly 1.8 meters (5.9 feet), this terminal port programming cable offers the ideal length for safely connecting your laptop to a control enclosure panel while maintaining a comfortable working distance. This data-link distance ensures you can safely monitor live I/O states and configure PLC logic outside the arc flash boundary or away from moving machinery components.

Documentation & Downloads

Specifications

Key Specifications

Country of Origin	China, United States

Physical Attributes

Cable Length	1.8 m

Important Information Attributes

Persona Type Ids	BM9, EU, OM, OM8, SC, SI, VR
Market Segmentation Id	COMMERCIAL, INDUSTRIAL
Range Of Product	Modicon M340 automation platform, Modicon M262
Accessory / Separate Part Designation	3.4" small touch screen panel, 3.5" small touch screen panel
Local Publishable Date	2026-01-12
Stocking Flag	Y
Device Type	PLC System - PLC Component
Traceability	No
Scope Perimeter	At least in Europe
Reach Full Compliance Status Id	NOT_CONTAINING_SVHC
Rohs Eur In Scope	No
Rohs Eur Conformity Date	1851
China Rohs In Scope	Yes
With Recycled Cardboard	Yes
Product Contributes To Saved And Avoided Emissions	No
Tier	1
Function Option	Standard
Electrical Connection	1 connector USB type A1 connector mini B USB M340 processor)
Returnability	Yes
Pep Code	ENVPEP1312019EN
Accessory / Separate Part Type	terminal port/USB cordset
Package Weight(Lbs)	53.0 g
Warranty (In Months)	18

Persona Type Names	Charge Point Operator, End User, Original Equipment Manufacturer, OEM - Control Panelbuilder, Electrician, System Integrator, IT Channel Partner
Market Segmentation	Commercial, Industrial
Accessory / Separate Part Destination	graphic terminal XBTGT, XBTGK, XBTGTW, PC terminal
Local Data Status	Publishable
Return Indicator	Y
Stock Policy	1
Serviceability	No
Weee Scope	Out
Reach Full Compliance Status	Free of Substances of Very High Concern above the threshold
Reach Compliance Directive	Free of Substances of Very High Concern above the threshold
Rohs Eur Status	Compliant
Rohs Eur Full Compliance Status	Compliant
China Rohs Label	1
Without Single Use Plastic	No
Tier Id	1
Function Option Id	STANDARD
Product Kit Identifier	N
Product Availability	Stock - Normally stocked in distribution facility
Sustainable Packaging	No
Accessory / Separate Part Category	connection accessories
Nbr. Of Units In Pkg.	1
Take-back	No
Customs Code	8544422000

Environment Attributes Main

Take Back	No
Recycled Metal Content At Cr Level	0 %
Toxic Heavy Metal Free	Yes
Environmental Disclosure	ENVPEP1312019EN
Packaging Made With Recycled Cardboard	Yes
Reach Free Of Svhc	Yes
Pep Code	ENVPEP1312019EN

Reach Free Shvc	Yes
China Rohs Regulation	X
Mercury Free	Yes
Eu Rohs Directive	Compliant
Packaging Without Single Use Plastic	No
Reach Regulation	Free of Substances of Very High Concern above the threshold
