nVent Hoffman UVT4554 Ventilation module, 455-670mm
- MPN: UVT4554
- UPC: 783510532079
- PPN: HOF-UVT4554
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
The ventilation module guarantees air circulation when many components are mounted and it can be installed wherever. This Ventilation Modules With Thermostat, UVT, UVT4554 item has a material of Mild Steel color Black, finish Powder Coated.
Features
- Description: Ventilation shelf with controller that regulates the temperature and air flow inside the racks. The unit consists of a fan controller and 2 or 4 fans inside a one unit shelf. The electronic sensor can be attached where the temperature is most critical (hot spot), close to your most expensive equipment, to ensure the correct temperature and air flow. The current temperature is displayed on the front of the unit, where it is possible to see preset values and intervals. The presence of an automatic control allows the system to switch on the ventilation only when the temperature goes beyond the operator preset value Thereby the equipment gets less dusty and the energy consumption is reduced as well as the sound level. In other words the ventilation system saves energy, but also prolongs the life of the ventilators, which are operating only when needed. Fully wired and ready to connect.
- Voltage: 200-235 V.
- Alternating current frequency: 50~60 Hz.
- Power of the fan: 22 Watt.
- Consumption current: 0.28A / 0.56A.
- Air circulation: 4.4 / 8.8 m³/min.
- Measurement limits: -50 ºC ... +125 ºC.
- Measurement accuracy: +/-0.5ºC.
- Working temperature: 0...+50ºC.
- Relative air humidity (air temp. +35C): 80%.
- Noise level: 35 decibel.
- Lifetime: 30.000 hours.
- Approvals: UL, CSA, VDE, TUV.
- Switch: No.
- Thermostat: Yes.
- Pack quantity: 1 unit including power cable (1.5 m) with Shuko plug and sensor cable (1.2 m). Version with 4 fans is supplied with a depth fixing bracket.
Documentation & Downloads
Specifications
Key Specifications
- BABA
- Contact Manufacturer
- Max Mounting Depth
- 670
- Works With
- IEC
- Material
- Mild Steel
- Color
- Black
Rack Units1
Fan Quantity4
Product FamilyFree-Standing
FinishPowder Coated
Enclosure MaterialMild Steel
