Tripp Lite B116-002A 2-Port DVI Splitter with Audio, Max Resolution 1920x1200, Signal Booster
- MPN: B116-002A
- UPC: 037332156747
- PPN: TRP-B116-002A
CAD
$201.98
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Spec sheet
Description
2-Port DVI Splitter with Audio, Max Resolution 1920x1200, Signal Booster
Features
- Transmits a DVI-D Single Link video signal and 3.5mm audio signal to two sets of DVI monitors and speakers
- Supports DVI Single Link computer video resolutions up to 1920 x 1200, and HD resolutions up to 1080p.
- Built-in signal booster extends the distance between the splitter and connected monitors past the 16 ft. (5 m.) distance limitation
- Expand the number of connected monitors/speakers by cascading up to 3 levels of splitters together
- Supports HDCP, EDID and DDC
- Compliant with the Federal Trade Agreements Act (TAA) for GSA Schedule purchases
- 3-year limited warranty
Documentation & Downloads
Specifications
Additional
- Max Resolution
- 1920 x 1200
- Ports
- 2
- Output Voltage
- 5V, 2A
- Side A Connector 1
- DVI-I (Female)
- Side B Connector 1
- (2) DVI-I (Female)
- Unit Dimensions (H x W x D)
- 1.1 x 4.5 x 2.5 in
- Operating Temperature Range
- 32 to 104 °F (0 to 40 °C)
- Operating Humidity Range
- 20 to 90%
- Signal Type
- DVI-D Single Link, Stereo Audio
- Cascading Levels
- 3 levels
- Color
- Black
Video Resolution1080p HD
Input Voltage100-240V, 50/60Hz, 0.5A
Max Range by Resolution65 ft for 1920 x 1200 and 1080p, 80 ft for lower resolutions
Side A Connector 23.5 mm (Female)
Side B Connector 2(2) 3.5 mm (Female)
Unit Weight0.5 lbs
Storage Temperature Range-4 to 140 °F (-20 to 60 °C)
Storage Humidity Range20 to 90%
Built-in Signal BoosterYes
ComplianceTAA, HDCP, EDID, DDC
