Cooper Lighting Solutions 22CGTS-NUV 2X2 CGT Selectable Lumens & CCT (3500K, 4000K, 5000K)
- MPN: 22CGTS-NUV
- UPC: 080083247837
- PPN: COL-22CGTS-NUV
- UNSPSC: 30161602
CAD
$68.85
/ EA
Available to Order
Available to Ship Same/Next Business Day if In Stock and Ordered before 12:00 PM EST
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Spec sheet
Description
2X2 CGT Selectable Lumens & CCT (3500K, 4000K, 5000K)
Features
- 24.313 IN Length 25.903 IN Width 2.785 IN Height
- 1x4, 2x2, and 2x4 sizes available
- Thin 2.5" inch height
- Selectable Lumens & CCT (3500K, 4000K, 5000K)
- 120-347V NUV Driver standard in all models
- DLC Certified
- Fits in shallow plenums with room to spare
- Robust die-formed steel housing is post-painted for maximum durability
- Acrylic microoptics provide uniform illumination from corner to corner
- Extruded aluminum bezel tightly sealed to the housing for durability
Documentation & Downloads
Specifications
Additional
- Voltage
- 120-347V
- Lumens
- 4686 Max
- Length
- 23-3/4 in
- Height
- 1-1/2 in
- Size
- 2x2
- Lamp Type
- LED
- Ingress Rating
- IP5X
- Dimming
- 0-10V, 10% standard
- CRI (Minimum)
- 85
- Country of Origin
- CN
Wattage40.3 W max
Color Temperature3500K, 4000K, 5000K
Width23-3/4 in
Weight6.5 lb
MountingCeiling Mount
MaterialSteel, Aluminum, Acrylic
Ambient Temperature Rating25°C
Efficacy Range110 to 130 lm/W
CertificationscULus Listed, UL Damp Location Listed, IC Rated, FCC Part 15 Class B, Title 24 High Efficiency, DLC Qualified
ARRA CompliantNo
