Blackburn X 1 N 102 Aluminum Compression Splice 5-1/2 Inch for 1/0 ACSR and 2/0 Stranded, Red
- MPN: X 1 N 102
- UPC: 783786759149
- PPN: T-B-X 1 N 102
- UNSPSC: 39121449
CAD
$17.86
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Spec sheet
Description
Aluminum 5-1/2 inch Service Entrance Compression Splice for Wire Range, End A: 1/0 ACSR, 2/0 Stranded, 1/0 Stranded Compact, Red, End B: 2 ACSR, 1-2 Stranded, Red, Die: 840. For AL to AL or AL to CU Conductors.
Specifications
Additional Information
- Brand / Label
- Homac
- Connection Type
- Compression
- Insulation Material
- Insulated
- Product Name
- ELECTRICAL SPLICE<1000V
- Size
- 5-1/2 inches long
- Standards
- ANSI C119.4
ColorYellow/Red
Effective Date20080619
Number of Conductors2
Product TypeCompression Splice Service Entrance Insulated
Special FunctionsSolid center barriers and large chamfers. Easy cable installation. Pre-filled with oxide inhibitor to prevent oxidation and keep out moisture. Constructed from Aluminum. Provides high conductivity. All splices are marked with installation die codes and compression locations for easy identificaton and installation. Tough Stabilized -Nylon Sleeves Rresist Installing-Tool Pressure and Provide Reliable 600V Insulation.
Ordering
- Country of Origin
- United States (US)
Selling Unit of Measureeach
Classifications
- WEEE Category
- Product Not in WEEE Scope
IDEA Granular Category Code (IGCC)4669 >> Wire or cable compression splice
