nVent Hoffman ASE16X16X6 Screw-Cover Enclosure Type 1 with Knockouts, 16x16x6, Gray, Steel
- MPN: ASE16X16X6
- UPC: 783510864507
- PPN: HOF-ASE16X16X6
- UNSPSC: 39121303
CAD
$53.63
/ EA
Available to Order
Available to Ship Same/Next Business Day if In Stock and Ordered before 12:00 PM EST
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Description
Screw-Cover Type 1 used in commercial and industrial applications requiring a junction or pull box. This Screw-Cover Type 1 with Knockouts, ASE16X16X6 item measures 16x16x6 inches with a material of Steel colored Gray.
Features
- Unique keyhole screw slots in the cover
- Available with or without knockouts
- Various sizes of easy-to-remove concentric knockouts on all four sides of standard boxes with knockouts
- Optional flush-mounted door frame available
- Optional flush covers
- Flat, removable covers fastened with plated steel screws
- Provision for grounding
- Mounting holes on back of box
- Enclosures are finished with paint over plated surfaces
Documentation & Downloads
Specifications
Additional
- Size
- 16.00 x 16.00 x 6.00 in
- Material
- Steel
- Color
- Gray (ANSI 61)
- Body Thickness
- 16 gauge (1.52 mm)
- Knockouts
- Yes, various sizes on all four sides, easy to remove (Pattern B-C-D-E-F-G-H)
- Provision for Grounding
- Yes
- IP Rating
- IP30
Weight15.4 lb
FinishGray polyester powder paint
Cover Thickness16 gauge (1.52 mm)
Cover Screw Quantity4
Mounting HolesOn back of box
NEMA RatingType 1 Indoor Electrical Protection
